- Table size: 1220 x 2440 mm
Larger models up to 2100mm x 11000mm available
High precision 5.2kW (7.0Hp) router with internal cooling fan and ER32 collet chuck.
Additional 2x 1.5Kw (2.0 Hp) Drilling spindles and ER20 collet chucks
On-board PC with user friendly Windows 7 operating system. Network interface facility for file sharing. File format for the controller software configured in
TOOL CALIBRATION PAD
The integrated sensor pad allows the operator to quickly and accurately calibrate each tool. The tool length is then automatically stored in the tool offset file.
PHENOLIC TABLE TOP
There are 4 individually controlled vacuum zones. The table surface has a gasket matrix configuration with T-Slots along the Y axis, allowing various vacuum options e.g. spoilboards and jigs.
Vacuum for the table top is provided by two quality 5.5kW(7.5Hp) rotary vane vacuum pump. These two pumps displaces 320 cubic metres per hour. Oil-free discharge gas is guaranteed, even in adverse operating conditions.
DRIVE GUIDE SYSTEM
Superior quality linear guides and bearings units are used on all three of the machine’s axis. Precise movement along the X and Y axis is achieved via induction hardened oblique rack and pinion drive systems. Z axis (vertical) movement accuracy is assured via a precision ground re-circulating ball screw.
